DMP50 GP

DMP50 GP

The DMP50 GP serves since 2013 industrial and R&D needs. It processes materials like Stainless Steel, Tungsten and highly reactive materials such as Titanium.

High detail resolution and accuracy, very good surface finish, low running cost and ease of use are it’ s highlights. Process and work safety is ensured by an purified inert Argon atmosphere and air locks to make sure the powder particles up to 5 µm size are processed safely. The flexible DMP50 GP serves the requirements for R&D work as well as the requirements for stable series production.

Main specifications:

  • Infrared Fiber Laser 50 Watt
  • Laser spot size ≤ 30 µm
  • Building platform Ø57 x 30 mm³
  • Layer thickness 1 µm to 5 µm
  • Inert Argon atmosphere
  • Gas tight design & gas cleaning – low running cost
  • Air locks and Rapid Transfer Ports
  • Processing of highly reactive materials

The DMP50 GP is the right choice for your start into the world of additive manufacturing of micro metal parts.
